Kyosho 32894 MINI-Z MR-04EVO2 W-MM 5600KV Chassis Set

Kyosho 32894 MINI-Z MR-04EVO2 W-MM 5600KV Chassis Set

Product Description:

Build a high-performance MINI-Z racer with the Kyosho 32894 MR-04EVO2 W-MM Chassis Set. Designed for experienced MINI-Z drivers, this factory-assembled chassis features a KYOSHO SPEED HOUSE XSPEED 56 5600KV sensored brushless motor and advanced electronics for precise, responsive control.

The MR-04EVO2 retains the proven MR-03 layout while introducing a redesigned front suspension, lower battery position and improved steering geometry. Its Front Suspension Arm 2.0 increases rigidity to provide more precise handling and greater stability on the track.

A factory-installed ball differential helps balance the speed of the rear wheels while cornering and provides controlled slip under heavy load for improved traction. The chassis also supports narrow and wide front tread settings, allowing it to be adjusted for compatibility with different MINI-Z body configurations.

The updated EVO2 electronics support high-speed communication with compatible receiver units and allow motor RPM settings to be adjusted through the I.C.S. Setting Manager.

Please note that this is a chassis set only. A compatible transmitter, receiver unit, Auto Scale body, wheels, tires and batteries are required separately.

Key Features:

• Factory-assembled MR-04EVO2 W-MM chassis
• Rear-wheel-drive MINI-Z racing platform
• KYOSHO SPEED HOUSE XSPEED 56 motor
• 5600KV sensored brushless motor
• High-rigidity Front Suspension Arm 2.0
• Redesigned front suspension geometry
• Kingpin-integrated front steering knuckles
• Adjustable narrow or wide front tread
• Low-mounted battery configuration
• Lower center of gravity for improved stability
• Seven low-resistance ball bearings
• Factory-installed ball differential
• Adjustable motor RPM through I.C.S. Setting Manager
• Compatible with EVO and EVO2 receiver units
• Includes multiple pinion gears for ratio adjustment

Specifications:

• Brand: Kyosho
• Product Line: MINI-Z Racer
• Product Type: Chassis Set
• Part Number: 32894
• UPC: 4548565518456
• Chassis: MR-04EVO2 W-MM
• Drive System: Rear-Wheel Drive
• Motor Type: Sensored Brushless
• Motor: KYOSHO SPEED HOUSE XSPEED 56
• Motor Rating: 5600KV
• Motor Mount: MM
• Length: 124.5mm
• Width: 72–76mm
• Height: 31mm
• Wheelbase: 98mm / LL
• Front Tread: 63.5–65mm
• Rear Tread: 61.5–65mm
• Gear Ratios: 7.3:1, 6.3:1, 5.5:1 and 4.9:1
• Weight: Approximately 135.5g without body, wheels or tires

Package Includes:

• Factory-assembled MR-04EVO2 W-MM chassis
• Installed 5600KV sensored brushless motor
• Front tread adjustment parts
• 6-tooth pinion gear
• 7-tooth pinion gear
• 8-tooth pinion gear
• 9-tooth pinion gear
• Wheel wrench
• Pinion gear tool
• Spare wheel nuts

Required for Completion:

• Compatible transmitter
• EVO or EVO2-compatible receiver unit
• Compatible MINI-Z Auto Scale body
• Compatible wheels and tires
• Four AAA batteries for the chassis
• Batteries for the transmitter

Important Information:

• This is not a complete Readyset.
• Body, wheels and tires are not included.
• Transmitter and receiver unit are not included.
• Gyro unit is not included.
• Batteries are not included.
